Description
<
Product name
Hot Melt Glue Cementing Machine
Model
DM-HM30
DM-HM40
DM-HM50
Voltage
220V /50HZ 1-phase
Power
2KW
Electric Heating
120 W
Working width
300 mm
400mm
500mm
Operating temperature
300℃
Material thickenss
0.5-10mm
Machine Dimensions
550*500*900mm
600*500*900mm
700*500*900
N.W.
40 kgs
50kgs
60kgs
G.W.
60kgs
70kgs
80kgs
Uses: Wet wipe boxes, gift boxes, shoemaking, leather goods, paper boxes, accessories, building materials, sports equipment, glasses boxes and other industries (large area of material is glued,instead of self-adhesive glue).
To Hot melt glue gluing machine, mainly suitable for pearl cotton gluing, packaging industry gluing, shoe industry gluing, special industry gluing, etc.
Features:
(1) It has a safety design to prevent the hands from being caught in the rollers, and to prevent the work objects from being caught in the glue tank.
(2) The coating width can be designed according to customer requirements, and the roller size can be selected from 30~300mm.
(3) The width of the cloth can be designed according to the work requirements, and the temperature of the glue groove and the roller can be controlled separately.
(4) The motor protection system is adopted to extend the life of the motor. The motor adopts stepless speed change, which is convenient for the use of large and small materials.
(5) Accurate over-temperature protection system
Features and performance
1. This machine is suitable for laminating and gluing flat surfaces with a thickness of 0.5mm or more, such as shoes, suitcases, leather goods,stationery, cardboard boxes, sports equipment, etc.
2. Innovative design The upper wheel seat can float up and down and the pressure speed can be adjusted evenly for uneven, soft, hard, high front and low back materials.
3. The hot-melt glue tank is treated by Teflon, which makes it easy to change the glue. The temperature can be adjusted according to the characteristics of the hot-melt glue, which can effectively prevent the hot-melt glue from carbonizing.
4. This machine is equipped with a constant
temperature device to protect the motor from malfunction, and is equipped with a suction and exhaust machine to eliminate peculiar smells.
5. The working power motor of this machine is controlled by a frequency converter, and the speed can be adjusted without variable speed.
